- Acrovyn PVC-Free
220mm high, HRB-50N combines a PVC-Free handrail and crash rail on a stainless steel bracket to provide mobility support and impact protection.
- Heavy Duty
- BS 8300 Compliant
- Dual Colour
- Code compliant hand/crash rail for busy circulation areas
- 40mm Ø handrail with textured cover over aluminium retainer for secure, comfortable grip
- 127mm high crash rail with curved cover over continuous aluminium retainer and shock-absorbing cushion for effective impact protection
- Infill strip closes off retainer channel for ease of cleaning
- Mounted on robust stainless steel brackets
- Solid Colours
Acrovyn PVC-Free (15)
Mounting
Colours & Finishes
- Solid Colours
Acrovyn PVC-Free (15)
* Zbog ograničenja ispisa i zaslona računala, stvarne boje mogu se razlikovati. Preporučujemo da odaberete boju iz naše besplatne palete uzoraka .
Approximate LRV values for CS Acrovyn colours and finishes have been determined using the CIE Y value measurement method.
Stock Lengths & Fixings
- Acrovyn PVC-Free: 3.0m
- Brackets at max. 800mm centres; fixing into studwork or pattresses is recommended
Pribor
Various accessories are available to aid the installation of our products, or to enhance their look.
- End caps
- External corners
- Internal corners available for handrail part
- Stainless steel mounting brackets
- Vertical accent trims/ collars (optional) – handrail: clear; crash rail: Black
